Swage Threaded Stud Tensioner End Fitting Terminal Cable Railing Hardware
Swage Threaded Terminals for your cable railings can be used to tension your cable runs. These are typically paired with a Swage Plain Terminal or another Swage Threaded Terminal. Swage Threaded Terminals are affixed to the cable using a hand (or machine) crimping tool.
Made from marine grade T316 stainless steel for maximum durability. Includes lock nut, washer, and cap nut.
Standard Structural Components
The Threaded Rod: Passes all the way through your end post. It is tightened from the outside with a washer and hex/acorn nut to pull the slack out of your wire rope.
The Swage Barrel: A hollow tube where the raw cable is inserted. It must be permanently crimped down using a manual or hydraulic swaging tool.
T316 Stainless Steel: The premier material rating required to completely resist rust, pitting, and oxidation in outdoor and harsh coastal environments.
Cable railing swage threaded stud tension end fitting terminals are the industry-standard hardware used to secure and tension 1/8" or 3/16" stainless steel cables through wood, metal, or aluminum posts.
Core Dimensions & Specs
Cable Sizes: Typically matched to standard 1/8" or 3/16" wire ropes.
Thread Sizing: Usually standard 1/4"-20 UNC threads or M6 metric threading.
Length Variations: Short studs (3-7/8" overall) are engineered for standard 2"x2" metal posts. Longer studs (6" overall) are designed to clear thick 4"x4" wood posts.
Step-by-Step Installation Basics
Thread the post: Drill a straight hole through your end post according to the manufacturer's recommended size (usually 1/4" or 5/16").
Measure and cut: Pull your cable taut to the end post, mark the entry depth of the swage barrel, and cut cleanly with a cable cutter.
Crimp the terminal: Insert the bare cable end into the hollow swage sleeve.
Use a hydraulic crimping tool to press the sleeve 2 to 3 times to lock the wire in place.
Tension the line: Feed the threaded stud through your post hole, slide on the washer, and tighten down the locknut until the line is perfectly stiff.
