marine-grade 316 stainless steel flush mount fishing rod holders featuring integrated bottom drains, UV/sunshine-resistant black PVC caps, and protective liners.
The inset circle callout details a crucial structural feature: a welded bottom drain tail fitting (barbed nipple). Instead of allowing rainwater, washdown water, or salt spray to drip directly under the deck into dry storage lockers or electronics cavities, this design allows you to connect a flexible drain hose to safely route water away into the bilge or overboard scuppers.
Structural Angles & Geometric Differences
The three rod holders represent the standard multi-angle fleet setup used along a boat's gunwales and transom to maximize your active fishing footprint:
• Left (90-Degree / Vertical): The top oval flange is perfectly perpendicular to the tube body. It is engineered for upright rod storage, acting as a "rocket launcher" setup, or as a secure vertical mount for deck accessories like cutting boards, bait tables, grills, and sunshades.
• Center (15-Degree Tilt): Built with a slight, shallow slant. This is primarily used along the transom or narrower gunwales where a mild outward angle is preferred for downriggers or flatlines.
• Right (30-Degree Tilt): The industry standard for offshore trolling. It slants the fishing rods dramatically outward past the beam of the boat, expanding your trolling spread and keeping active lines separated to prevent tangling during tight turns.
Are you replacing existing rod holders and trying to match their flange size, or do you need help determining the ideal spacing and hole saw sizes for cutting new mounts into a clean fiberglass or aluminum gunwale?
Haifan Rigging supply a range of marine boat hardwares. They come with a variety of fittings for each end to suit your particular application. Yachts, Sailboats, Ships and Other Fields.
If you wish to ask a question or need further advice, you are welcome to contact us. We'll be happy to help.
We look forward to hearing from you!
